650nm 5V Laser Module

The 650nm 5V Laser Module is a compact and easy-to-use laser diode module that emits a visible red laser beam. It is widely used in Arduino and DIY electronics projects for alignment, detection, and signaling applications. With a built-in driver circuit, it can be directly powered using a 3V–5V supply, making it ideal for beginners and robotics projects.

Features:

• 650nm Red Laser: Produces a bright visible red dot beam
• Low Power Consumption: Typically operates around 30–40mA
• Plug & Play: Works directly with 3V–5V power supply
• Built-in Driver Circuit: Stable operation without extra components
• Compact Design: Easy to integrate into small projects
• Breadboard Friendly: Simple connection with jumper wires
• High Precision Beam: Suitable for alignment and positioning
• Easy Control: Can be controlled using Arduino digital pins

Specifications:

• Wavelength: 650nm (red visible light)
• Operating Voltage: 3V – 5V DC
• Operating Current: ~40mA
• Output Power: ≤5mW (typical)
• Driver Circuit: Built-in APC driver
• Beam Type: Red dot laser
• Wire Length: ~135mm
• Dimensions: ~6mm diameter module
• Control: VCC (+), GND (–), optional signal pin
